Monitor Audio Radius 90 Compact 2-way Bookshelf Speaker (Pair)
- 100% brand new original products
- Official manufacturer’s warranty valid in India
- Price includes GST & Shipping
- Check for EMI & Pay on Delivery Options
Country of Origin: United Kingdom
Color: High Gloss Black / Satin White
Warranty: 1 Year
The original hi-fi mini monitor, and respected by all. Monitor Audio Radius 90 continues to evolve and packing a punch with an enhanced size-defying performance than ever before.Radius 90 includes a 4” (100 mm) C-CAM bass driver and 1” (25 mm) C-CAM tweeter for a tuneful, controlled and powerful sound in pairs or brought together as front and rear speakers in an AV system along with the 200 or 225, and the 380 or 390 sub. Use the optional MASM speaker mount or any standard wall bracket for wall mounting via the 90’s single point fixing. Optional floor stands expand the set-up possibilities still further.
Performance That Outpaces the Size
The compact Monitor Audio Radius 90 is a surround speaker with a size-defying performance. Its secret is the 4″ C-CAM Driver and a 1″ rear-firing gold C-CAM tweeter, which spreads and magnifies the sound around the room to deliver a huge, encompassing surround sound effect. All drivers are dedicated and model specific, with each model in the Radius series being meticulously designed and voiced individually.
HiVe II Port Design Helps Reduce Turbulence
Straight from Platinum’s design blueprint, the HiVe reflex port makes its Radius debut. It’s shaped to have the same effect on airflow as a gun-barrel on a bullet. Rifled grooves inside the port help to accelerate the flow and reduce turbulence, so air moves in and out of the port with enhanced efficiency, for a faster more dynamic bass response.
Single Through-Bolt Driver Fixing Renders Mechanical Decoupling Properties
Single through-bolt driver fixing provides mechanical de-coupling properties resulting in enhanced mid-band clarity and resolution. Through-bolts also act as rigid cross bracing to give a very solid non-resonant cabinet. It is also feature-packed with single point ¼” x 20TPI wall fixing. Feel free to use the optional Monitor Audio speaker mount or any standard wall bracket or optional floor-stand with an internal (pre-wired) cable management system.
- 4" C-CAM bass/mid driver
- Rear-firing 1" C-CAM gold dome tweeter
- Single through-bolt driver fixing
- Single point ¼" x 20TPI wall fixing
- Optional floor-stand with internal (pre-wired) cable management system
- Available in the Radius range of real-wood veneer, lacquer and grille colour options
|Frequency Response||80 Hz — 35 kHz|
|Sensitivity (1W@1M)||83 dB|
|Nominal Impedance||8 ohms|
|Power Handling (RMS)||75 W|
|System Power Handling (RMS)||100 W|
|Recommended Amplifier Requirements||30 — 100 W|
|Maximum SPL||102 dBa|
|Bass Alignment||Bass reflex - Rear ported|
|Drive Unit Complement||1 x 4" (100 mm) C-CAM cone bass/mid driver
1 x 1" (25 mm) C-CAM Gold Dome tweeter
|Cabinet Dimensions (H x W x D)||198 x 125 x 140 mm (713/16 x 415/16 x 51/2")|
|Cabinet Dimensions (Including Grille and Terminals (H x W x D))||198 x 125 x 164 mm (713/16 x 415/16 x 67/16")|
|Cabinet Dimensions (Including Grille and Bracket (H x W x D))||198 x 125 x 203 mm (713/16 x 415/16 x 8")|
|Pre-Construction Bracket||Optional - Monitor Audio Speaker Mount (MASM)|
|Weight||2.1 kg (4 lb 10 oz)|
