Bowers & Wilkins 803 D4 Floor standing loudspeaker (Pair)
- 100% brand new original products
- Official manufacturer’s warranty valid in India
- Price includes GST & Shipping
- Check for EMI & Pay on Delivery Options
Country of Origin: United Kingdom
Color: Gloss Black / White / Satin Rosenut / Satin Walnut
Warranty: 1 Year
B&W’s most compact headed model brings all the technical benefits of a dedicated midrange enclosure – the Turbine™ Head, with its decoupled midrange cone – to a smaller footprint that’s effortlessly accommodated in any home. Bowers & Wilkins 803 D4 features all the most iconic ingredients in the 800 Series Diamond range including, of course, that glorious headed enclosure. It is, however, much more compact than its other siblings. Step up to the 802 D4, and you’ll get both larger 200mm (8in) bass cones and a larger 150mm (6in) midrange driver. Step up for more power.
Small Wonder That Packs a Punch
Bowers & Wilkins 803 D4 may be notably more compact than the 801 D4 or 802 D4, but it still bristles with technical innovation, most obviously in its use of a three-box construction. Its 130mm (5in) midrange cone is carefully isolated from the impact of its bass cones thanks to its Turbine Head enclosure.
Reverse Wrap Cabinet
Instead of a traditional loudspeaker box, B&W’s cabinets are crafted from a continuous curved section of wood, with the drive units mounted at the heart of the curvature. This stiffer, more inert structure resists mechanical resonances far better and also ensures better dispersion of sound.
Enhanced Matrix™ Creates a Believable Soundstage
Matrix bracing uses interlocking panels to reinforce loudspeaker cabinet walls in all directions internally, reducing resonance and creating a more believable soundstage. The Matrix assembly in 803 D4 is our best yet, ensuring optimum scale, power and intelligibility.
Aluminium Bass Pods
803 D4 mounts two Aerofoil™ bass cones in twin solid aluminium bass pods, each of which is clamped into an aluminium plate fixed to the stiffest part of its curved cabinet. Formed as single pieces of metal, these stiff structures provide the perfect mechanical location for those dynamic bass cones.
- Diamond tweeter
- Solid body Tweeter-on-Top
- Continuum cone FST™
- Anti-Resonance plug
- Biomimetic Suspension
- Turbine Head
- Aerofoil cone bass units
|Technical Features||Diamond tweeter
Solid body Tweeter-on-Top
Continuum™ cone FST
Aerofoil™ cone bass units
|Description||3-way vented-box system|
|Drive units||1x ø25mm (1in) Diamond dome high-frequency
1x ø130mm (5in) Continuum cone FST midrange
2x ø180mm (7in) Aerofoil cone bass units
|Frequency Range||16Hz to 35kHz|
|Frequency response||19Hz to 28kHz (+/-3dB from reference axis)|
|Sensitivity||90dB (on axis at 2.83Vrms at 1m)|
|Harmonic distortion||2nd and 3rd harmonics (90dB,1m on axis)
<1% 80Hz – 20kHz <0.3% 100Hz – 20kHz
|Nominal impedance||8Ω (minimum 3.0Ω)|
|Recommended amplifier power||50W – 500W into 8Ω on unclipped programme|
|Max recommended cable impedance||0.1Ω|
|Cabinet finishes||Gloss Black
