Monitor Audio C2M-T2X In-Ceiling Speaker (Pc)
- 100% brand new original products
- Official manufacturer’s warranty valid in India
- Price includes GST & Shipping
- Check for EMI & Pay on Delivery Options
Country of Origin: United Kingdom
Color: White
Warranty: 1 Year
Description
Monitor Audio C2M-T2X
Ideal for both music and movies, the medium-sized Tier 2 in-ceiling C2M-T2X allows the user to switch between Music mode for wide dispersion and Movie mode for spatial effects. It is a two-way model featuring an RST II dual-coil bass driver and two C-CAM tweeters.
Monitor Audio C2M-T2X has three modes:
- Cinema Mono FX (Di-Pole, tweeters out of phase)
- Mono Wide Dispersion (Bi-Pole, tweeters in phase)
- Single Speaker Stereo (two binding posts accepting connection to two separate amplifier channels)
C2M-T2X is ideal used as rear surround channels, within corridors or large areas where maximum coverage is required, and in compact areas where there isn’t space to fit two speakers.
Key Features
- Ideal for installations where pristine acoustic performance is required.
- Switchable design for three modes
- Two-way design
- 2 x 1" (25 mm) C-CAM tweeters with UD Waveguide II for lifelike sound
- 1 x 7" (178 mm) RST II dual-coil bass driver for pristine mid-range and full bass
- Patented Quik-Link speaker cable connector for quicker installation (UK patent application no. 2216966.8)
- Tri-Grip II for easy and secure fitment
Technical Specs
| Technical Details | |
|---|---|
| System Format | 2–Way |
| Channels | 1 (Mono) 2 (Stereo) |
| Frequency Response, Installed (-6dB) | 35 Hz – 30 kHz |
| Nominal Impedance | 4 Ohm (Mono) 8 Ohm (Stereo) |
| Minimum Impedance (20Hz to 20kHz) | 3.4 Ohm @ 15 kHz (Mono) 6.8 Ohm @ 15 kHz (Stereo) |
| Sensitivity (2.83Vrms@1m, Installed) | 86 dB |
| Maximum Peak SPL* (single speaker @ 1m Z-Weighted) | (Mono) 114 dB |
| Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor) | 150 W (Mono) 2 x 75 W (Stereo) |
| Recommended Amplifier Power (RMS into 8 OHM, Music Signal) | 40-150 W (Mono) 2 x 75 W (Stereo) |
| Drive Unit Complement | 1 x 7" (178 mm) RST II dual-coil bass driver 2 x 1" (25 mm) C-CAM tweeter |
| Crossover Frequency | LF/HF: 2.25 kHz |
| Mounting Depth | 99 mm (37/8”) |
| Cut-Out Hole Diameter | 212 mm (83/8") |
| External Dimensions (Including Grille (H x W x D)) | 242 x 242 x 103 mm (91/2 x 91/2 x 44/16") |
| Weight | 2.1 kg (4 lb 10 oz) |
| Pre-Construction Bracket | CM-B |
| Cabinet Finish | Matt black & Orange |
| Sold As | Single Unit |
| Corner Switch | On/Off |
| HF Switch | - /0/ + |
| Mono/Stereo Switch | Mono/Stereo |
| Music/Movie Switch | Music/Movie |
